Salient Features Lot
- • Fully automatic-Cum-Manual Controls
- • Efficiency upto 99%
- • Compact & light in weight, can be installed almost anywhere.
- • Smokeless hence Chimney not required
- • Maintains neat & clean surroundings
- • Completely factory assembled
- • Absolutely Sate
- • Exempted from Boiler act
Applications
- • Health Clubs
- • Laboratories
- • Hotels
- • Engineering & Research Institutions
- • Pharmaceutical Industries
- • Chemical Plants
- • Food Processing Industries
- • Laundries
- • Dairy industry
- • Soap Industry
- • Tanneries and many other Industries requiring small quantity of Steam.
Technical Specifications
| MODEL NO. FVE | 25 | 50 | 75 | 100 | 150 | 200 | 300 | 400 | 600 | |
| Evaporation Capacity Kg/Hr | 25 | 50 | 75 | 100 | 150 | 200 | 300 | 400 | 600 | |
| Electrode KW | 18 | 36 | 54 | 72 | 108 | 144 | 216 | 288 | 432 | |
| Pump HP | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.75 | 1.0 | |
| L | 1500 | 1500 | 1500 | 1500 | 2200 | 2200 | 2500 | 2600 | 2750 | |
| Overall damnations mm | W | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 |
| H | 1100 | 1100 | 1100 | 1100 | 1250 | 1250 | 1250 | 1250 | 1250 | |
| Dry Weight (Approx)KG | 200 | 200 | 225 | 250 | 375 | 375 | 400 | 500 | 575 | |
NOTE : Our Constant endeavor is to improve the design and performance as a consequence of which the specifications are subject to. change without notice. Power requirement 3-phrase, 440V
