Construction and Salient Features :
- • Its designed on the principle of indirect heat transfer in shell and tube type heat exchanger having forced circulation to give you long life of electric heater and thermic fluid.
- • Fully Automatic operation save on electric bill.
- • Completely factory assembled and compact, so no special foundation required.
- • High thermal Efficiency (97%)
- • Suitable for outlet temp. up to 300 deg. C.
- • Easy in maintenance as individual heaters can be removed without stopping operation.
- • Outside the preview of Indian Boiler Regulation Act.
Technical Specifications
| MODEL NO. | RATED OUTPUT KCAL/HR | POWER REQUIRED HEATER | OVER ALL DIMENSIONS | |||
| HEATER | PUMP MOTOR | L | W | H | ||
| FET 9 | 7740 | 9KW | 1 HP | 1350 | 1000 | 800 |
| FET 18 | 15480 | 18 KW | 1.5 HP | 1350 | 1000 | 900 |
| FET 36 | 30960 | 36 KW | 2 HP | 1350 | 1350 | 1250 |
| FET 54 | 46440 | 54 KW | 3 HP | 1400 | 1400 | 1250 |
| FET 72 | 61920 | 72 KW | 3 HP | 1400 | 1450 | 1300 |
| FET 108 | 92880 | 108 KW | 3 HP | 1400 | 1600 | 1400 |
| FET 144 | 123840 | 144 KW | 3 HP | 1500 | 2200 | 1800 |
| FET 180 | 154800 | 180 KW | 5 HP | 1650 | 2400 | 1800 |
| FET 240 | 206400 | 240 KW | 7.5 HP | 1650 | 2800 | 2000 |
| FET 300 | 256000 | 300 KW | 7.5 HP | 1650 | 3000 | 2200 |
NOTE : Our Constant endeavor is to improve the design and performance as a consequence of which the specifications are subject to. Change without notice. Power requirement 3-phrase, 440V
